Attention: If an electronic ignition system is installed, do not touch conductive parts with the ignition on. Therefore, to check the ignition spark, hold the ignition cable or spark plug tip only with well-insulated pliers, or attach the tip to the engine with adhesive tape.
Attention: When connecting the ignition cables, pay attention to the ignition sequence 1-3-4-2.
Remove the ignition distributor cap. There is a label on the side of the ignition distributor housing. Install the distributor cap.
The ignition cable of the 1st cylinder is installed above the label. Start the engine for a short time. In the direction of rotation of the ignition distributor slider, the ignition cables for cylinders 3-4-2 follow.
Measure the voltage at terminal 15 of the ignition coil with a voltmeter. Some of the following rules should be followed to avoid high voltage shock.
Connect a voltmeter to terminal 15 and ground. Terminal 1 wire, ignition coils, connect to ground.
Turn on the starter and measure the input voltage with a voltmeter.
The voltage must be at least 9 V.
